Key details: Model: META-6KW Rated Power: 6KVA / 6KW Phase: 1-phase in / 1-phase out Maximum PV Input Power: 4500W × 2 = 9000W Maximum DC Voltage: 500VDC Start-up Voltage: 90VDC MPPT Voltage Range: 60V – 450VDC MPPT Trackers / Max Input Current: 2 / 18A Grid-Tied Operation Grid Feed Output: 3000W Nominal Output Voltage: 220 / 230 / 240VAC Output Voltage Range: 195.5 – 253VAC Nominal Output Current: 26.5A Power Factor: >0.99 Efficiency (DC to AC): Up to 97% Off-Grid Operation (AC Input) Start-up / Auto Restart Voltage: 170–280VAC / 180VAC (UPS Mode) Input Voltage Range: 90–280VAC Frequency Range: 50Hz / 60Hz (Auto Sensing) Max AC Input Current: 26.5A General Dimensions (mm): 360.7 × 278 × 106 Weight: 4.92 kg Communication Port: Built-in RS232 / Wi-Fi (optional) IP Protection: IP21 Operating Temp: -10°C to 50°C Storage Temp: -15°C to 60°C Humidity: 5% – 95% (Non-condensing)
